Optimize Wireless Signals with our Antennas
Description
AG-2450-15D Wi-Fi Dual Bands Parabolic Grid Antennas
Easy Installation Lightweight Robust against high speed wind
Learn more on our blog : From Wireless to IoT : AsiaRF’s Journey of Innovation
Features
- It is ideally suited for 2.4GHz ISM band applications such as IEEE 802.11b/g/n wireless LAN systems.
- This simplifies installations since the same antenna can be used for a wide array of outdoor wireless applications where wide coverage is desired.
- Point to Point Systems & Point to Multi-point Systems
Standard
| Frequency Range | 2400 – 2500 MHz | 5150 – 5900 MHz |
| Polarization | Linear | |
| Gain(dBi) | 15dBi | 17dBi |
| Horizontal Beamwidth | 16° | |
| Vertical Beamwidth | 21° | |
| Impedance | 50Ω | |
| VSWR | ≤ 1.5 | |
| Maximum Power | 50W | |
| Connector Type | 1 Port, N-Type Female | |
| Antenna Dimension(mm) | 300*400 | |
| Net Weight | 1.2kg | |
| Operating Temperature | -55° to +60° C (-67° to +140° F) | |
| Radome Material | Aluminum | |
| Mounting Options | Hanged on pole | |
Weight 1.4 kg
Additional information
| Weight | 1.3 kg |
|---|---|
| Dimensions | 31 × 10 × 24 cm |
