XSquare 5G Data Card XS5G04-GBO A-U
Original price was: $230.00.$180.00Current price is: $180.00.
The XS5G04-GBO A-U data card provides robust support for 5G/4G/3G networks through a USB interface.
It integrates the MediaTek 5G solution, built upon 3GPP Release 15 technology.
This product is manufactured in Taiwan.
The XS5G04-GBO A-U data card provides robust support for 5G/4G/3G networks through a USB interface.
It integrates the MediaTek 5G solution, built upon 3GPP Release 15 technology.
This product is manufactured in Taiwan.
XSquare-Service mail address: [email protected]
Learn more on our blog : From Wireless to IoT : AsiaRF’s Journey of Innovation
XS5G04-GBO_A-U 5G Data Card Specification
| 5G NR | |
| Standard | 3GPP Release 15 |
| SA Bands | n77/78/79 |
| Bandwidth | 100 MHz |
| DL 4×4 MIMO | n77/78/79 |
| UL 2×2 MIMO | n77/78/79 |
| 4G LTE | |
| LTE Bands | – |
| 3G UMTS/WCDMA | |
| WCDMA Bands | – |
| GPS | |
| Standard | GPS/GLONASS/BeiDou/Galileo |
| Frequency Band | L1 |
| Main Data Through(peak) | |
| 5G NR DL/UL | 2.3Gbps / 1.25Gbps |
| 4G DL/UL | 600Mbps / 150Mbps |
| 3G DL | 42.2Mbps (HSDPA) |
| 3G UL | 11.5Mbps |
| Certifications | |
| Standard | FCC / CE / JRF&JPA / NCC |
| Hardware | |
| Package | M.2 module (key B) |
| SOC | MediaTek T700 series (MT6880VU) / Integrates ARM Corex-A55 |
| Flash | MCP 4Gb+4Gb |
| Power Supply | 3.135V-3.63V, typical: 3.3V |
| Interfaces | USB 2.0 / USB 3.0 / SIM |
| GPIO (Reset / Power / LED ) / UART | |
| RF Antenna port | ANT0: 617 MHz ~ 5000 MHz |
| ANT1: 1805 MHz ~ 5000 MHz | |
| ANT2: 1710 MHz ~ 5000 MHz | |
| ANT3: 617 MHz ~ 5000 MHz | |
| Dimensions | 52mm x 30mm x 2.4mm (Max) |
| Weight | 8.7g |
| Operation Temp | -30 ~ +70 ℃ |
| Storage Temp | -40 ~ +90 ℃ |
| Software | |
| Update/ Management. | Firmware update via PCI-e |
| OS Version. | TBD (Depends on host OS) Module support from Linux 4.19 |
| Drivers | USB 3.0 MBIM |
| Pin define | ||||
| Pin No. | Pin Name | Pin No. | Pin Name | |
| 74 | +3.3V | 75 | CONFIG_2 (GND) | |
| 72 | +3.3V | 73 | VIO_CFG (NC) | |
| 70 | +3.3V | 71 | GND | |
| 68 | NC | 69 | CONFIG_1 (GND) | |
| 66 | SIM Detect (I) (1.8V) | 67 | RESET# (I) (1.8V) | |
| 64 | COEX1 (IO) (1.8V) | 65 | ANTCTL3 (O) (1.8V) | |
| 62 | COEX2 (IO) (1.8V) | 63 | ANTCTL2 (O) (1.8V) | |
| 60 | COEX3 (IO) (1.8V) | 61 | ANTCTL1 (O) (1.8V) | |
| 58 | MIPI2_D_SDATA (IO) (1.8V) | 59 | ANTCTL0 (O) (1.8V) | |
| 56 | MIPI2_D_SCLK (O) (1.8V) | 57 | GND | |
| 54 | PEWake# (IO) (3.3/1.8V) | 55 | REFCLKP | |
| 52 | CLKREQ# (IO) (3.3/1.8V) | 53 | REFCLKN | |
| 50 | PERST# (IO) (3.3/1.8V) | 51 | GND | |
| 48 | NC | 49 | PERp0 | |
| 46 | NC | 47 | PERn0 | |
| 44 | I2C_IRQ# (I) (1.8V) | 45 | GND | |
| 42 | I2C_SDA (IO) (1.8V) | 43 | PETp0 | |
| 40 | I2C_SCL (O) (1.8V) | 41 | PETn0 | |
| 38 | NC | 39 | GND | |
| 36 | USIM1_PWR (O) | 37 | USB3.0_RX+ | |
| 34 | USIM1_DATA (IO) | 35 | USB3.0_RX- | |
| 32 | USIM1_CLK (O) | 33 | GND | |
| 30 | USIM1_RESET (O) | 31 | USB3.0_TX+ | |
| 28 | I2S0_LRCK (IO) (1.8V) | 29 | USB3.0_TX- | |
| 26 | W_DISABLE2# (I) (3.3/1.8V) | 27 | GND | |
| 24 | I2S0_DO (O) (1.8V) | 25 | DPR (I) (1.8V) | |
| 22 | I2S0_DI (I) (1.8V) | 23 | WOWWAN# (IO) (1.8V) | |
| 20 | I2S0_BCK (IO) (1.8V) | 21 | CONFIG_0 (GND) | |
| Notch | Notch | |||
| Notch | Notch | |||
| Notch | Notch | |||
| Notch | Notch | |||
| 10 | LED1# (O) (3.3V) | 11 | GND | |
| 8 | W_DISABLE1# (I) (3.3/1.8V) | 9 | USB_D- | |
| 6 | FULL_CARD_POWER_OFF# (I) (3.3/1.8V) | 7 | USB_D+ | |
| 4 | +3.3V | 5 | GND | |
| 2 | +3.3V | 3 | GND | |
| 1 | CONFIG_3 (NC) | |||
| Weight | 0.015 kg |
|---|---|
| Dimensions | 9.5 × 6.5 × 1.5 cm |
