Universal LoRa Node is a perfect experimental LoRa control node.
Default Temperature, Humidity, Vibration sensors.
- Universal LoRa Node
- Fully Support LoRaWAN 1.0.2
- RS485, DI/DO, AI/AO, IoT
- Default Temperature, Humidity, Vibration sensors
- M0 MCU can be programmed to any applications and sensors data collection
- MCU build in AES 128-bit key encryption hardware accelerator
Board Main Interfaces:
| 3 x DI/DO | 1 x DC 5V |
| 1 x DC 12V | 1 x RS485 |
Specification
| Basic | |
| SoC / Main Chipset | STM32L063C8 |
| LoRa Module | S76S |
| Power Source | DC 9V – 24V |
| Product Size (L x W x H) | 98 x 95 x 20 mm |
| Temperature | Storage: -50 to +105℃
Operating: -40 to +85℃ |
| Humidity | 10% to 95% |
| Wireless Interface | |
| Standard Compliance | LoRaWAN 1.0.2 |
| Operation Frequency | 863 to 870MHz, 902 to 928MHz |
| Antenna | External Antenna with SMA male connector |
| Range | 2 KM |
| Speed | Max 27 k bytes |
| Wireless Security | AES |
| Environment | |
| Operating temperatures | -20 to 85 C degrees |
| Storage temperatures | -40 to 105 C degrees |
| Operating humidity | from 10% to 95% |
| Non-Operating humidity | from 5% to 95% |
Weight 0.3 kg
